General Info

Speeds:
1 x 9

Weight:
25.7 kg (56.7 lb)

Gear Inches:
33" - 97" (2.65 - 7.72 m)

Folding Size:
163 × 40.5 × 86 cm (64.2 × 15.9 × 33.9 in)

Folding Time:
5 sec

Frame Sizes:
One size

Distance: Seatpost to Handlebar:
49 - 59 cm (19.3 - 23.2 in)

Distance: Saddle to Pedal:
69 - 105 cm (27.2 - 41.3 in)

Suggested Rider Height:
150 - 195 cm (59.1 - 76.8 in)

Max Gross Vehicle Weight:
170 kg (374.8 lb)

Max Rider Weight:
120 kg (264.6 lb)

Frame

Frame:
Tern HSD, 6061-AL, patented design, Tern sliding dropouts, EFBE Tri-Test approved: 170 kg

Fork:
Suntour custom for Tern, Chromoly steerer, 32 mm stanchions, Thru-axle, EFBE tested for 170 kg


Cockpit

Handlepost:
Tern Physis 3D (G2), 3D forged, 5 patented technologies, 12°, 290 mm

Stem:
Tern Andros (G2), adjustable, forged construction, patented technology

Headset:
Tern Flux, cartridge bearings, Physis integrated

Handlebar:
Tern Sweep, 6061-AL, Tern Andros adapted

Grips/Bar Tape:
Ergon

Saddle:
Tern HSD

Seatpost:
Tern Telescope, 34.9/30.9 mm, 2014-AL

Seatpost Clamp:
Tern Collar, 6061-AL, 2pc

Brakes

Front Brake:
Shimano, hydraulic disc, 180 mm rotor

Rear Brake:
Shimano, hydraulic disc, 160 mm rotor

Brake Levers:
Shimano, hydraulic disc

Brake Cable & Housing:
Shimano, hydraulic disc

Wheels

Front Wheel:
Tern Atlas H cargo, wide 35mm, Novatec Thru-axle, 100mm, 32H

Rear Wheel:
Tern Atlas H, wide 35mm, ShimanoDisc, 135mm, 32H

Front Hub:
Novatec, Thru-axle, sealed bearings

Rear Hub:
Shimano disc

Spokes & Nipples:
Stainless steel

Rims:
Tern Atlas H, wide 35 mm

Tires:
Schwalbe Big Apple, 406, 20×2.15 F/V

Transmission

Shifter(s):
Shimano Alivio, trigger, 1×9 spd.

Rear Derailleur:
Shimano Alivio Shadow, 9 spd.

Crankset:
Tern HSD custom, 52T

Cassette/Freewheel:
Shimano 11-32T, 9 spd

Bottom Bracket:
Motor integrated

Chain:
9 spd, DHT for eBike, GST corrosion resistant coating

Pedals:
Urban with non-slip surface

Shifter Cable & Housing:
Jagwire LEX-SL, slick treatment, alloy ferrules


E-System

Motor:
Bosch Active Line Plus(24km/h)

Battery:
Bosch PowerPack 300Wh, 36V/8.2Ah

Display:
Bosch Intuvia

Range:
42 -100 km (26-69 mi)

Charger:
Bosch Standard Charger, 100-240V, 800g, 190×86×54mm


Bells & Whistles

Bell:
Aluminum

Chainguard:
SKS Chainblade

Kickstand:
Ursus, rear mount

Luggage Socket:
Combo Mount

Front Light:
Tern Valo Direct, 45 lux/190 lumens

Rear Light:
Herrmans H-Trace, for eBike

Fenders:
SKS, stainless hardware

Rack(s):
Atlas H Rack™, Atlas Rack Mount, 6 point mounting; Max load weight: 60 kg (132 lb)

Accessory:
ABUS 5650L, keyed-alike with Bosch battery
