GENERAL INFO

SPEEDS:
1 x 8
WEIGHT:
21.5 kg (47.4 lb)
GEAR INCHES:
32" – 94" (2.58 – 7.50 m)
FOLDING SIZE:
79 × 38 × 72 cm (31.1 × 15 × 28.3 in)
FOLDING TIME:
10 seconds
FRAME SIZES:
One size
DISTANCE: SEATPOST TO HANDLEBAR:
61 - 61 cm (24 - 24 in)
DISTANCE: SADDLE TO PEDAL:
65 - 93 cm (25.6 - 36.6 in)
SUGGESTED RIDER HEIGHT:
160 - 190 cm (63 - 74.8 in)
MAX GROSS VEHICLE WEIGHT:
120 kg (264.6 lb)
MAX LOAD WEIGHT:
105 kg (231.5 lb)


FRAME

FRAME:
Tern Vektron, hydroformed aluminum, OCL+ joint, 3 patented technologies
FORK:
Integrated, hi-tensile steel


COCKPIT

HANDLEPOST:
Tern Physis 3D (G2), 3D forged, 5 patented technologies
STEM:
Fixed height, forged QR
HEADSET:
Tern Flux, cartridge bearings, Physis integrated
HANDLEBAR:
Flat bar, 6061-AL, Tern Andros adapted
GRIPS/BAR TAPE:
Velo ergonomic, lock-on
SADDLE:
Tern Porter, patented GripPad design
SEATPOST:
SuperOversize, 34.9mm, 6061-Al, micro-adjust clamp
SEATPOST CLAMP:
Oversize, 6061-AL


BRAKES

FRONT BRAKE:
Clarks, hydraulic disc
REAR BRAKE:
Clarks, hydraulic disc
BRAKE LEVERS:
Clarks, hydraulic disc
BRAKE CABLE & HOUSING:
Clarks, hydraulic disc


WHEELS

FRONT WHEEL:
Double wall, Shimano, 100 mm, Centerlock disc mount, w/QR
REAR WHEEL:
Double wall, Shimano, 135 mm, Centerlock disc mount, w/QR
FRONT HUB:
Shimano disc
REAR HUB:
Shimano disc
SPOKES AND NIPPLES:
Stainless steel
RIMS:
Kinetix Comp, for disc
TIRES:
Schwalbe Big Apple, Active Line, 50-406, puncture protection, Reflex


TRANSMISSION

SHIFTER(S):
Shimano, 1 x 8 spd, trigger
FRONT DERAILLEUR:
n/a
REAR DERAILLEUR:
Shimano Altus Shadow
CRANKSET:
Vektron custom, forged 6061-AL crankarm
CASSETTE/FREEWHEEL:
Shimano 11-32T, 8 spd
BOTTOM BRACKET:
Motor integrated
CHAIN:
8 spd, DHT for eBike, GST corrosion resistant coating
PEDALS:
Folding, alloy body
SHIFTER CABLE & HOUSING:
Anti-compression housing, slick cables


E-SYSTEM

MOTOR:
Bosch Active Line Plus, max speed 24 kph
BATTERY:
Bosch PowerPack 300
DISPLAY:
Bosch Purion
RANGE:
300 Wh: 40 -114 km (25-71 mi) 100V, 4A (JP)


BELLS & WHISTLES

BELL:
Aluminum, Aluminum
KICKSTAND:
URSUS, rear mount
CLIP SYSTEM:
Magnetix 3.0
LUGGAGE SOCKET:
Yes
FENDERS:
RP Chromeplastic, stainless hardware
