tern ターン〖12/31までの限定特価〗2024 LINK D8 [リンクD8]


カラーバリエーション

マウスをあわせると上記写真を変更します

  • セーフティーイエロー/シルバー

商品詳細

☆★12月31日までの期間限定セール!!★☆

お取り寄せ品となります。
お気軽にお問い合わせくださいませ





GENERAL INFO


SPEEDS:
1 x 8

WEIGHT:
12.1 kg (26.7 lb)

GEAR INCHES:
33" - 87" (2.60 - 6.94 m)

FOLDING SIZE:
38 × 79 × 72 cm (15 × 31.1 × 28.3 in)

FOLDING TIME:
10 sec

FRAME SIZES:
One size

DISTANCE: SEATPOST TO HANDLEBAR:
62 - 69 cm (24.4 - 27.2 in)

DISTANCE: SADDLE TO PEDAL:
70 - 96 cm (27.6 - 37.8 in)

SUGGESTED RIDER HEIGHT:
142 - 190 cm (55.9 - 74.8 in)

MAX GROSS VEHICLE WEIGHT:
120 kg (264.6 lb)

MAX RIDER WEIGHT:
105 kg (231.5 lb)


FRAME


FRAME:
Tern Link, aluminum, OCL+ joint, 3 patented technologies

FORK:
Integrated, hi-tensile steel


COCKPIT


HANDLEPOST:
Tern Physis 3D (G2), 3D forged, 5 patented technologies, 12°, 350 mm

STEM:
Tern Andros (G2), adjustable, forged construction, patented technology

HEADSET:
Flux, cartridge bearings, Physis integrated

HANDLEBAR:
Flat bar, 6061-Al, Andros butted

GRIPS/BAR TAPE:
Velo ergonomic, lock-on

SADDLE:
BioLogic Como DLX

SEATPOST:
SuperOversize, 6061-AL, micro-adjust clamp

SEATPOST CLAMP:
SuperOversize, 6061-AL


BRAKES


FRONT BRAKE:
V, aluminum, linear spring

REAR BRAKE:
V, aluminum, linear spring

BRAKE LEVERS:
V, aluminum bracket/lever

BRAKE CABLE & HOUSING:
Anti-compression housing, slick cables


WHEELS


FRONT HUB:
Mini, aluminum, QR

REAR HUB:
Formula, 8 spd cassette

SPOKES AND NIPPLES:
Sapim Leader, stainless steel

RIMS:
Doublewall aluminum

TIRES:
Schwalbe Big Apple, 50-406, puncture protection, Reflex


TRANSMISSION


SHIFTER(S):
Shimano, 1 x 8 spd, trigger

REAR DERAILLEUR:
Shimano Claris

CRANKSET:
Forged 6061 aluminum crank arms, hand-polished

CASSETTE/FREEWHEEL:
11-32T, 8 spd

BOTTOM BRACKET:
Cartridge, sealed bearings

CHAIN:
8 spd.

PEDALS:
Folding, alloy body

SHIFTER CABLE & HOUSING:
SP


BELLS & WHISTLES


BELL:
Aluminum

KICKSTAND:
Deluxe center mount

CLIP SYSTEM:
Magnetix 2.0

LUGGAGE SOCKET:
Yes

FRONT LIGHT:
Opt: Tern Valo 2, integrated, 41 lux/150 lumens

REAR LIGHT:
Opt: Deluxe LED

FENDERS:
RP Chromeplastic, stainless hardware

RACK(S):
Opt: Tern Loader Rack
